APPLICATION : |
| |
For Foods / Pharmaceuticals / Chemicals / Electronics /
Electroplating / Plastics/Mesh plate print etc.
Product Preheating / Baking / Drying / Experiment
kind etc. |
| ★ |
FEATURE : |
| |
▲ |
Circle system heater and control box all are
located at machine side or upside, temp. Constancy, over temp. Drying finish and explosion proof complete automatically during operation. |
| ▲ |
Easy to move & install, small space, low price, Recover quickly, is apply for best widespread
equipemnt. |
| ★ |
ORDER : |
| |
▲ |
Depend on product different specification size,
control material & model etc. Designed make or
coordination with others equipment. |
| ▲ |
Product kind characteristic capacity shape weight
drying time and temp. |
| |
▲ |
Product if is inflammable basic or acid. |
| Model |
AM-4 |
AM-5 |
AM-6 |
AM-7 |
| Interior Dim. (WxDxH) (cm) |
100x60x100 |
120x60x120 |
140x80x120 |
180x100x160 |
| Exterior Dim. (WxDxH) (cm) |
125x75x170 |
146x75x190 |
170x98x190 |
210x118x235 |
| Temp. Range (℃) |
200 ℃ |
200 ℃ |
200 ℃ |
200 ℃ |
| Temp. Accuracy (℃) |
0.3 ~ 1 |
0.3 ~ 1 |
0.3 ~ 1 |
0.3 ~ 1 |
| Temp. Uniformity (℃) |
2 ~ 3 |
2 ~ 4 |
2 ~ 4 |
2 ~ 5 |
| Heating Time (min) |
9 |
8 |
8 |
8 |
| Max. Power (kw) |
8 |
12 |
14 |
18 |
| AC Power Source |
220 V / 380 V |
220 V / 380 V |
220 V / 380 V |
220 V / 380 V |
| Trolley Grid |
20 |
24 |
24 |
32 |
| Tray Size |
43x58x5 |
53x58x5 |
63x78x5 |
83x98x5 |
| Door |
2 |
2 |
2 |
2 |
| Circulation |
Double |
Double |
Double |
Double |
| Weight (kg) |
250 |
300 |
360 |
500 |
|
|
